ISL97692IIZ-T
IC LED DRV RGLTR PWM 16WLCSPManufacturer: Renesas Electronics Corporation
Categories: LED Drivers
Quality Control: Learn More
The Renesas Electronics Corporation ISL97692IIZ-T is a 4-output DC-DC boost LED driver IC. This device features integrated switches and supports PWM dimming with a frequency range of 400kHz to 1.5MHz. Each of the four channels delivers a regulated output current of 40mA, with a maximum output voltage of 26V. The ISL97692IIZ-T operates from a supply voltage range of 2.4V to 5.5V. It is housed in a compact 16-WLCSP (1.66x1.66) package, suitable for surface mounting. This highly integrated solution is designed for backlight applications in various electronic displays. The component is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-UFBGA, WLCSP |
| Voltage - Output | 26V |
| Mounting Type | Surface Mount |
| Number of Outputs | 4 |
| Frequency | 400kHz ~ 1.5MHz |
| Type | DC DC Regulator |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 40mA |
| Internal Switch(s) | Yes |
| Topology | Step-Up (Boost) |
| Supplier Device Package | 16-WLCSP (1.66x1.66) |
| Dimming | PWM |
| Voltage - Supply (Min) | 2.4V |
| Voltage - Supply (Max) | 5.5V |
