EL5172ISZ-T7
IC OPAMP DIFF 1 CIRCUIT 8SOICManufacturer: Renesas Electronics Corporation
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Renesas Electronics Corporation EL5172ISZ-T7 is a single-circuit, high-performance operational amplifier designed for demanding applications. This device features a differential amplifier configuration with a push-pull output stage, delivering a 100 MHz gain bandwidth product and a rapid 800V/µs slew rate. The -3dB bandwidth extends to 250 MHz, making it suitable for high-speed signal processing. Operating with a supply voltage span from 4.75V to 11V, it consumes a low 5.6mA of quiescent current. The EL5172ISZ-T7 is presented in an 8-SOIC (0.154", 3.90mm Width) surface-mount package, supplied on tape and reel. Key specifications include a 6 µA input bias current and a 7 mV input offset voltage. This component finds utility in instrumentation and buffer amplifier applications across various industrial sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Push-Pull |
| Mounting Type | Surface Mount |
| Amplifier Type | Differential |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 5.6mA |
| Slew Rate | 800V/µs |
| Gain Bandwidth Product | 100 MHz |
| Current - Input Bias | 6 µA |
| Voltage - Input Offset | 7 mV |
| Supplier Device Package | 8-SOIC |
| Number of Circuits | 1 |
| -3db Bandwidth | 250 MHz |
| Voltage - Supply Span (Min) | 4.75 V |
| Voltage - Supply Span (Max) | 11 V |
