EL5166ISZ-T13
IC OPAMP CFA 1 CIRCUIT 8SOICManufacturer: Renesas Electronics Corporation
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Renesas Electronics Corporation EL5166ISZ-T13 is a single-circuit current feedback amplifier designed for high-speed applications. This device offers a -3dB bandwidth of 1.4 GHz and a slew rate of 6000V/µs, making it suitable for demanding signal processing tasks. It operates with a supply voltage span from 5V to 12V and consumes 8.5mA of quiescent current. The input bias current is rated at 8.5 µA, with an input offset voltage of 500 µV. The EL5166ISZ-T13 is housed in an 8-SOIC package, suitable for surface mounting. This component is commonly utilized in video processing, active filters, and high-frequency instrumentation.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | Current Feedback |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 8.5mA |
| Slew Rate | 6000V/µs |
| Current - Input Bias | 8.5 µA |
| Voltage - Input Offset | 500 µV |
| Supplier Device Package | 8-SOIC |
| Number of Circuits | 1 |
| -3db Bandwidth | 1.4 GHz |
| Voltage - Supply Span (Min) | 5 V |
| Voltage - Supply Span (Max) | 12 V |
