ISL99227BFRZ-TS2792
ISL99227BFRZ-TS2792Manufacturer: Renesas Electronics Corporation
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Renesas Electronics Corporation's ISL99227BFRZ-TS2792 is a highly efficient half-bridge driver designed for demanding DC-DC converter applications, including synchronous buck topologies. This component features a 32-PQFN (5x5) package for optimal thermal performance and board space utilization. It supports a load voltage range of 4.5V to 18V with a supply voltage of 4.75V to 5.25V. The ISL99227BFRZ-TS2792 delivers up to 60A output current per channel and integrates robust fault protection mechanisms, including current limiting, over-temperature shutdown, shoot-through prevention, and undervoltage lockout (UVLO). Key features include an integrated bootstrap circuit for high-side MOSFET driving and a status flag for system monitoring. The device utilizes a PWM interface and is suitable for inductive and capacitive load types. Operating across a temperature range of -40°C to 125°C (TJ), this component is ideal for automotive and industrial power systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit, Status Flag |
| Packaging | Bulk |
| Package / Case | 32-PowerWFQFN |
| Mounting Type | Surface Mount |
| Interface | PWM |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 4.75V ~ 5.25V |
| Rds On (Typ) | 16Ohm |
| Applications | DC-DC Converters, Synchronous Buck Converter |
| Current - Output / Channel | 60A |
| Current - Peak Output | - |
| Technology | MOSFET (Metal Oxide) |
| Voltage - Load | 4.5V ~ 18V |
| Supplier Device Package | 32-PQFN (5x5) |
| Fault Protection | Current Limiting, Over Temperature, Shoot-Through, UVLO |
| Load Type | Inductive, Capacitive |
