ISL97701IRZ-T13
IC REG BOOST ADJ 1.2A 10DFNManufacturer: Renesas Electronics Corporation
Categories: DC DC Switching Regulators
Quality Control: Learn More
The Renesas Electronics Corporation ISL97701IRZ-T13 is a high-frequency, synchronous boost switching regulator. This component is designed for step-up voltage conversion, featuring an adjustable positive output with a minimum voltage of 4.3V and a maximum of 28V. It can deliver up to 1.2A of switch current and operates with a switching frequency of 1MHz. The device supports input voltages ranging from 2.3V to 5.5V. Its 10-VFDFN exposed pad package facilitates efficient surface mounting. The ISL97701IRZ-T13 is suitable for applications in consumer electronics, battery-powered devices, and industrial control systems, operating across a temperature range of -40°C to 85°C. It is supplied in a tape and reel (TR) package.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-VFDFN Exposed Pad |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up |
| Current - Output | 1.2A (Switch) |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 1MHz |
| Voltage - Input (Max) | 5.5V |
| Topology | Boost |
| Supplier Device Package | 10-DFN (3x3) |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 28V |
| Voltage - Input (Min) | 2.3V |
| Voltage - Output (Min/Fixed) | 4.3V |
