ISL8105CRZ-T
IC REG CTRLR BUCK 10DFNManufacturer: Renesas Electronics Corporation
Categories: DC DC Switching Controllers
Quality Control: Learn More
Renesas Electronics Corporation ISL8105CRZ-T is a highly efficient, synchronous buck controller designed for step-down DC-DC conversion. This single-phase, positive output device operates with a switching frequency of 300kHz and supports a maximum duty cycle of 100%. Featuring integrated current limit and enable control functions, the ISL8105CRZ-T is built on a buck topology and utilizes a transistor driver for its output. The component is supplied in a 10-DFN (3x3) package, suitable for surface mount applications. Its operating temperature range is 0°C to 70°C (TA), and it requires a supply voltage between 6.5V and 14.4V. This controller is commonly employed in power supply designs across industrial and consumer electronics sectors. The product is available in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-VFDFN Exposed Pad |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Down |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 300kHz |
| Topology | Buck |
| Voltage - Supply (Vcc/Vdd) | 6.5V ~ 14.4V |
| Supplier Device Package | 10-DFN (3x3) |
| Synchronous Rectifier | Yes |
| Control Features | Current Limit, Enable |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 100% |
| Clock Sync | No |
| Number of Outputs | 1 |
