ISL68301IRAZ-TR5825
ICManufacturer: Renesas Electronics Corporation
Categories: DC DC Switching Controllers
Quality Control: Learn More
The Renesas Electronics Corporation ISL68301IRAZ-TR5825 is a single-phase, positive output, step-down DC-DC controller IC featuring a Digital-DC™ architecture. This device is designed for efficient power conversion and offers advanced control features including current limit, enable, power good indication, programmable ramp, soft start, and tracking capabilities. Its operating temperature range is -40°C to 85°C (TA). The ISL68301IRAZ-TR5825 supports a switching frequency range of 200kHz to 1MHz and a maximum duty cycle of 90%. Communication and configuration are managed through integrated I2C, PMBus, and SMBus serial interfaces. This component is housed in a 24-QFN (4x4) package with an exposed pad, suitable for surface mounting. Applications for this versatile controller can be found across various industries, including telecommunications, industrial automation, and data centers, where precise and efficient voltage regulation is critical.
Additional Information
Series: Digital-DC™RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 24-VFQFN Exposed Pad |
| Output Type | PWM Signal |
| Mounting Type | Surface Mount |
| Function | Step-Down |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 200kHz ~ 1MHz |
| Topology | Buck |
| Voltage - Supply (Vcc/Vdd) | 4.75V ~ 16V |
| Supplier Device Package | 24-QFN (4x4) |
| Synchronous Rectifier | No |
| Control Features | Current Limit, Enable, Power Good, Ramp, Soft Start, Tracking |
| Serial Interfaces | I2C, PMBus, SMBus |
| Output Phases | 1 |
| Duty Cycle (Max) | 90% |
| Clock Sync | Yes |
| Number of Outputs | 1 |
