ISL6741IV
IC REG CTRLR MULT TOP 16TSSOPManufacturer: Renesas Electronics Corporation
Categories: DC DC Switching Controllers
Quality Control: Learn More
Renesas Electronics Corporation's ISL6741IV is a versatile DC-DC controller IC designed for high-efficiency power conversion. This 16-TSSOP component, part number ISL6741IV, supports multiple topologies including Full-Bridge, Half-Bridge, and Push-Pull configurations, enabling both step-up and step-down voltage regulation with isolation-capable outputs. It features a maximum switching frequency of up to 1MHz and a duty cycle up to 83%, making it suitable for demanding applications. Control features include Enable, Frequency Control, and Soft Start, with a synchronous rectifier for enhanced performance. The ISL6741IV operates within a supply voltage range of 9V to 16V and across an industrial temperature range of -40°C to 105°C. Its robust design and dual output capabilities find application in power supplies for computing, industrial automation, and telecommunications.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | Up to 1MHz |
| Topology | Full-Bridge, Half-Bridge, Push-Pull |
| Voltage - Supply (Vcc/Vdd) | 9V ~ 16V |
| Supplier Device Package | 16-TSSOP |
| Synchronous Rectifier | Yes |
| Control Features | Enable, Frequency Control, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 83% |
| Clock Sync | Yes |
| Number of Outputs | 2 |
Request a Quote
