IDT2308A-3DC8
IC MULT ZDB 16SOICManufacturer: Renesas Electronics Corporation
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
The Renesas Electronics Corporation IDT2308A-3DC8 is a 1:8 multiplier, zero-delay buffer designed for clock distribution. This component features a maximum operating frequency of 133.3MHz and utilizes LVTTL input and output signaling. The device integrates a Phase-Locked Loop (PLL) with bypass functionality, enabling flexible clock generation and synchronization. Packaged in a 16-SOIC (0.154", 3.90mm Width) format for surface mounting, it operates within a voltage range of 3V to 3.6V. The IDT2308A-3DC8 is commonly employed in telecommunications, networking, and computing applications where precise clocking is critical. The component is supplied on tape and reel.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Output | LVTTL |
| Frequency - Max | 133.3MHz |
| Type | Multiplier, Zero Delay Buffer |
| Input | LVTTL |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3V ~ 3.6V |
| Ratio - Input:Output | 1:8 |
| Differential - Input:Output | No/No |
| Supplier Device Package | 16-SOIC |
| PLL | Yes with Bypass |
| Divider/Multiplier | No/Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
