ICS8430BYI-71LFT
IC FREQ SYNTH 32TQFPManufacturer: Renesas Electronics Corporation
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
Renesas Electronics Corporation ICS8430BYI-71LFT is a high-performance frequency synthesizer designed for demanding applications. This device features a maximum output frequency of 700MHz and utilizes an LVPECL output interface. The ICS8430BYI-71LFT integrates a Phase-Locked Loop (PLL) with bypass functionality, enabling flexible clock generation. It supports a 1:2 input-to-output ratio and includes internal divider/multiplier capabilities. The component is supplied in a 32-TQFP (7x7) package, suitable for surface mount installation. It operates within a voltage range of 3.135V to 3.465V and is rated for operation between -40°C and 85°C. This frequency synthesizer finds utility in telecommunications infrastructure, high-speed networking, and other applications requiring precise clock management.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-LQFP |
| Mounting Type | Surface Mount |
| Output | LVPECL |
| Frequency - Max | 700MHz |
| Type | Frequency Synthesizer |
| Input | Crystal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.135V ~ 3.465V |
| Ratio - Input:Output | 1:2 |
| Differential - Input:Output | No/Yes |
| Supplier Device Package | 32-TQFP (7x7) |
| PLL | Yes with Bypass |
| Divider/Multiplier | Yes/No |
| Number of Circuits | 1 |
| Programmable | Not Verified |
