ISL99202IRTAZ-TK
IC AMP CLASS AB STER 70MW 12TQFNManufacturer: Renesas Electronics Corporation
Categories: Audio Amplifiers
Quality Control: Learn More
Renesas Electronics Corporation ISL99202IRTAZ-TK is a 2-channel Class AB stereo audio amplifier IC. This surface mount component, packaged in a 12-TQFN (3x3) with an exposed pad, delivers up to 70mW per channel into a 16 Ohm load, suitable for headphone applications. Key features include integrated depop circuitry, comprehensive short-circuit and thermal protection, and a shutdown function for power management. The ISL99202IRTAZ-TK operates within a voltage supply range of 2.4V to 5.5V and is designed for operation in ambient temperatures from -40°C to 85°C. This device finds application in portable electronics, consumer audio systems, and communication devices. The component is supplied on a Tape & Reel (TR).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Depop, Short-Circuit and Thermal Protection, Shutdown |
| Packaging | Tape & Reel (TR) |
| Package / Case | 12-WFQFN Exposed Pad |
| Output Type | Headphones, 2-Channel (Stereo) |
| Mounting Type | Surface Mount |
| Type | Class AB |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2.4V ~ 5.5V |
| Max Output Power x Channels @ Load | 70mW x 2 @ 16Ohm |
| Supplier Device Package | 12-TQFN (3x3) |
