9FGL0651BKILF
IC CLOCK GENERATOR 40VFQFPManufacturer: Renesas Electronics Corporation
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Renesas Electronics Corporation 9FGL0651BKILF, a PCIe Clock/Frequency Generator, provides a robust solution for high-speed timing applications. This electronic component features a single 1:7 ratio output, capable of generating a 100MHz clock frequency from a crystal input. The device supports HCSL and LVCMOS output formats, essential for interfacing with PCIe peripherals. Designed for surface mount installation, the 9FGL0651BKILF is housed in a 40-VFQFPN (5x5) package with an exposed pad for enhanced thermal performance. Operating within a temperature range of -40°C to 85°C, its PLL circuitry ensures precise frequency generation. This component is widely utilized in networking, telecommunications, and computing industries where reliable PCIe clocking is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 40-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Output | HCSL, LVCMOS |
| Frequency - Max | 100MHz |
| Input | Crystal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.135V ~ 3.465V |
| Main Purpose | PCI Express (PCIe) |
| Ratio - Input:Output | 1:7 |
| Differential - Input:Output | No/Yes |
| Supplier Device Package | 40-VFQFPN (5x5) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
