97ULP877BHLF
IC CLOCK DRIVER 1.8V LP 52-BGAManufacturer: Renesas Electronics Corporation
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Renesas Electronics Corporation's 97ULP877BHLF is a low-power DDR2 clock buffer/driver designed for memory applications. This zero-delay buffer features a multiplexer and operates at frequencies up to 410MHz. It provides 10 outputs from a single clock input, utilizing SSTL-18 signaling for its outputs. The 97ULP877BHLF supports a voltage supply range of 1.7V to 1.9V and is packaged in a 52-CABGA (4.5x7.0) configuration for surface mounting. This component is suitable for use in systems requiring high-speed memory clock distribution, including computing and networking infrastructure. The device incorporates a PLL for precise clock generation and synchronization.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 52-VFBGA |
| Mounting Type | Surface Mount |
| Output | SSTL-18 |
| Frequency - Max | 410MHz |
| Input | Clock |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 1.7V ~ 1.9V |
| Main Purpose | Memory, DDR2 |
| Ratio - Input:Output | 1:10 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 52-CABGA (4.5x7.0) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
Request a Quote
