97U2A845AHLF
IC CLOCK DRIVER 28-CABGAManufacturer: Renesas Electronics Corporation
Categories: Application Specific Clock/Timing
Quality Control: Learn More
Renesas Electronics Corporation 97U2A845AHLF is a DDR2 clock buffer/driver featuring zero-delay buffering capabilities. This multiplexer IC operates at a maximum frequency of 410MHz, providing a 1:5 ratio for input to output. Designed for high-speed memory interfaces, specifically DDR2, its output signaling conforms to SSTL-18 standards. The component is packaged in a 28-CABGA (4.0x4.5) for surface mounting and operates within a temperature range of 0°C to 70°C. Its differential input/output configuration is supported. This device is commonly utilized in computing, server, and networking applications requiring precise clock distribution for memory systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 28-VFBGA |
| Mounting Type | Surface Mount |
| Output | SSTL-18 |
| Frequency - Max | 410MHz |
| Input | Clock |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 1.7V ~ 1.9V |
| Main Purpose | Memory, DDR2 |
| Ratio - Input:Output | 1:5 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 28-CABGA (4.0x4.5) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
