KAD5514P-21Q48
IC ADC 14BIT SAR 48QFNManufacturer: Renesas Electronics Corporation
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
Renesas Electronics Corporation KAD5514P-21Q48 is a 14-bit successive approximation register (SAR) analog-to-digital converter (ADC). This component features a single input channel with a sampling rate of up to 210 MSPS. It offers a 1:1 ratio for sample-and-hold to ADC functionality and utilizes an internal reference. The KAD5514P-21Q48 supports both LVDS and parallel data interfaces. Designed for surface mounting, it is housed in a 48-QFN (7x7) package with an exposed pad. The analog and digital supply voltage range is 1.7V to 1.9V, with an operating temperature range of -40°C to 85°C. This device is commonly found in applications such as high-speed data acquisition, telecommunications infrastructure, and medical imaging systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Package / Case | 48-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Number of Bits | 14 |
| Configuration | S/H-ADC |
| Data Interface | LVDS - Parallel, Parallel |
| Reference Type | Internal |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 1.7V ~ 1.9V |
| Voltage - Supply, Digital | 1.7V ~ 1.9V |
| Sampling Rate (Per Second) | 210M |
| Input Type | Differential |
| Number of Inputs | 1 |
| Supplier Device Package | 48-QFN (7x7) |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
