HI3-0303-5Z
IC SWITCH SPDT X 2 50OHM 14DIPManufacturer: Renesas Electronics Corporation
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Renesas Electronics Corporation HI3-0303-5Z is a dual 2:1 analog switch featuring SPDT configuration for each of the two circuits. This through-hole component, packaged in a 14-PDIP, offers a maximum on-state resistance of 50 Ohms, suitable for applications requiring minimal signal attenuation. Operating across a temperature range of 0°C to 75°C, it supports single supply voltages from 5V to 34V and dual supplies from ±5V to ±20V. Key specifications include a charge injection of 30pC and off-state leakage currents of 5nA. Typical applications include signal routing in test and measurement equipment, audio processing, and telecommunications systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | 0°C ~ 75°C (TA) |
| On-State Resistance (Max) | 50Ohm |
| -3db Bandwidth | - |
| Supplier Device Package | 14-PDIP |
| Voltage - Supply, Single (V+) | 5V ~ 34V |
| Voltage - Supply, Dual (V±) | ±5V ~ 20V |
| Charge Injection | 30pC |
| Crosstalk | - |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | - |
| Switch Time (Ton, Toff) (Max) | 300ns, 250ns |
| Channel Capacitance (CS(off), CD(off)) | 16pF, 14pF |
| Current - Leakage (IS(off)) (Max) | 5nA |
| Number of Circuits | 2 |
