HI1-0547-5
IC MUX DUAL 8:1 1.8KOHM 28CERDIPManufacturer: Renesas Electronics Corporation
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Renesas Electronics Corporation HI-0547-5 is a dual 8:1 analog multiplexer/demultiplexer featuring 2 circuits per device. This component offers an on-state resistance of 1.8 kOhm (max) and channel-to-channel matching (?Ron) of 126 Ohm. It operates with dual supply voltages up to ±15V and exhibits typical off-state leakage current (IS(off)) of 30 pA. Switching times are approximately 300 ns (Ton, Toff). The HI-0547-5 is housed in a 28-CerDip package suitable for through-hole mounting. This device finds application in various industrial and telecommunications systems requiring precise signal routing.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 28-CDIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Operating Temperature | 0°C ~ 75°C (TA) |
| On-State Resistance (Max) | 1.8kOhm |
| -3db Bandwidth | - |
| Supplier Device Package | 28-CerDip |
| Voltage - Supply, Single (V+) | - |
| Voltage - Supply, Dual (V±) | ±15V |
| Charge Injection | - |
| Crosstalk | - |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 126Ohm |
| Switch Time (Ton, Toff) (Max) | 300ns, 300ns (Typ) |
| Channel Capacitance (CS(off), CD(off)) | 10pF, 30pF |
| Current - Leakage (IS(off)) (Max) | 30pA (Typ) |
| Number of Circuits | 2 |
Request a Quote
