QBSLDIG301GR
DISPLAY 7SEG 0.3"" SGL GRN 10DIPManufacturer: QT Brightek (QTB)
Categories: LED Character and Numeric
Quality Control: Learn More
Display Modules - LED Character and Numeric Green 7-Segment 1 Character Common Cathode 3V 20mA 0.500"" H x 0.299"" W x 0.250"" D (12.70mm x 7.60mm x 6.35mm) 10-DIP (0.200"", 5.08mm)
Additional Information
Series: QBSLDXX30ZGRRoHS Status: ROHS3 CompliantManufacturer Lead Time: 11 week(s)Product Status: ActivePackaging: BagDatasheet:Download Free CAD Model:&mpn=QBSLDIG301GR&lbl=1&lbc=000000&q3=1)
Technical Details:
| Packaging | Bag |
| Package / Case | 10-DIP (0.200"", 5.08mm) |
| Color | Green |
| Display Type | 7-Segment |
| Size / Dimension | 0.500"" H x 0.299"" W x 0.250"" D (12.70mm x 7.60mm x 6.35mm) |
| Number of Characters | 1 |
| Millicandela Rating | 84mcd |
| Common Pin | Common Cathode |
| Digit/Alpha Size | 0.30"" (7.62mm) |
| Voltage - Forward (Vf) (Typ) | 3V |
| Current - Test | 20mA |
| Wavelength - Peak | 520nm |
| Power Dissipation (Max) | 64mW |
