X-2629-TWT-R
BUZZER PIEZO 12V 25MM THManufacturer: PUI Audio, Inc.
Categories: Alarms, Buzzers, and Sirens
Quality Control: Learn More
Buzzers Indicator, Internally Driven Piezo 12 V 35mA 2.9kHz 107dB @ 12V, 10cm Through Hole PC Pins
Additional Information
Series: XRoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Size / Dimension | 0.984"" Dia (25.00mm) |
| Mounting Type | Through Hole |
| Frequency | 2.9kHz |
| Operating Temperature | -40°C ~ 85°C |
| Sound Pressure Level (SPL) | 107dB @ 12V, 10cm |
| Duration | - |
| Current - Supply | 35mA |
| Input Type | DC |
| Operating Mode | Single Tone |
| Voltage Range | 5 ~ 14V |
| Technology | Piezo |
| Termination | PC Pins |
| Approval Agency | - |
| Ratings | Washable |
| Port Location | Top |
| Driver Circuitry | Indicator, Internally Driven |
| Height - Seated (Max) | 0.917"" (23.30mm) |
| Voltage - Rated | 12 V |
