PS21964-4
MOD IPM 600V 15A SUPERMINIDIPManufacturer: Powerex Inc.
Categories: Power Driver Modules
Quality Control: Learn More
The Powerex Inc. Intellimod™ PS21964-4 is a 3-phase Intelligent Power Module (IPM) designed for high-power applications. This IGBT-based module offers a robust 600V breakdown voltage and a continuous current rating of 15A. Featuring a 1500VDC isolation voltage, the PS21964-4 employs a 25-PowerDIP Module package with a through-hole mounting type, measuring 1.134" (28.80mm). Its integrated driver circuitry simplifies system design and enhances reliability. Applications for this component include industrial motor drives, uninterruptible power supplies (UPS), and renewable energy systems. The PS21964-4 is supplied in bulk packaging.
Additional Information
Series: Intellimod™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 25-PowerDIP Module (1.134"", 28.80mm) |
| Mounting Type | Through Hole |
| Type | IGBT |
| Configuration | 3 Phase |
| Voltage - Isolation | 1500VDC |
| Current | 15 A |
| Voltage | 600 V |
