LNK576DG
IC OFFLINE SWITCH FLYBACK 8SOManufacturer: Power Integrations
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
Power Integrations LinkZero™-LP Series LNK576DG is an 8-SOIC (0.154", 3.90mm Width), 7 Leads offline switch IC designed for flyback topologies. This device operates at a switching frequency of 100kHz and offers a maximum power output of 9W. It features integrated switching capabilities and provides robust fault protection including current limiting, open loop, over temperature, over voltage, and short circuit protection. The LNK576DG is suitable for surface mount applications with an operating temperature range of -40°C to 150°C (TJ). Its isolated output and 700V breakdown voltage make it a reliable choice for AC-DC conversion in consumer electronics and industrial applications.
Additional Information
Series: LinkZero™-LPRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width), 7 Leads |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Duty Cycle | 63% |
| Frequency - Switching | 100kHz |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Supplier Device Package | SO-8C |
| Fault Protection | Current Limiting, Open Loop, Over Temperature, Over Voltage, Short Circuit |
| Control Features | - |
| Power (Watts) | 9 W |
