LNK562GN
IC OFFLINE SWITCH FLYBACK 8SMDManufacturer: Power Integrations
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
Power Integrations LinkSwitch®-LP series LNK562GN is an 8-SMD (7 leads), Gull Wing package, offline flyback converter IC. This component is designed for 66kHz switching frequency and features an internal 700V breakdown voltage switch with a 70% duty cycle. It offers robust fault protection including current limiting, open loop, over temperature, and short circuit protection. The LNK562GN provides isolated output and is suitable for surface mount applications. Operating temperature range is -40°C to 150°C (TJ). This device finds application in industries such as consumer electronics and industrial power supplies.
Additional Information
Series: LinkSwitch®-LPRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SMD (7 Leads), Gull Wing |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Duty Cycle | 70% |
| Frequency - Switching | 66kHz |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Supplier Device Package | SMD-8B |
| Fault Protection | Current Limiting, Open Loop, Over Temperature, Short Circuit |
| Control Features | - |
| Power (Watts) | 1.9 W |
