LNK354GN-TL
IC OFFLINE SWITCH FLYBACK 8SMDManufacturer: Power Integrations
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
Power Integrations LinkSwitch®-HF LNK354GN-TL is an 8-pin SMD offline flyback converter IC, operating at 200kHz. This component integrates a high-voltage power MOSFET, enabling efficient, high-performance power supply designs. It features built-in current limiting, over-temperature, short-circuit, and open-loop fault protection for robust operation. The device supports up to 5W output power and offers isolated output with a 700V breakdown voltage. Its compact SMD-8B package with gull wing leads is suitable for surface mount applications. This device finds extensive use in consumer electronics, industrial controls, and smart home appliances. The LNK354GN-TL is supplied in tape and reel packaging.
Additional Information
Series: LinkSwitch®-HFRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SMD (7 Leads), Gull Wing |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Duty Cycle | 63% |
| Frequency - Switching | 200kHz |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Supplier Device Package | SMD-8B |
| Fault Protection | Current Limiting, Open Loop, Over Temperature, Short Circuit |
| Control Features | - |
| Power (Watts) | 5 W |
