LNK353GN-TL
IC OFFLINE SWITCH FLYBACK 8SMDManufacturer: Power Integrations
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
The Power Integrations LinkSwitch®-HF series LNK353GN-TL is an 8-SMD (7 leads), Gull Wing isolated flyback offline converter. This device operates at a switching frequency of 200kHz with a maximum duty cycle of 63%. It integrates an internal switch and offers robust fault protection including current limiting, open loop, over temperature, and short circuit protection. Designed for surface mounting, the LNK353GN-TL is supplied in a Tape & Reel (TR) package. Its 700V breakdown voltage makes it suitable for AC DC power supply applications across various industries, including consumer electronics and industrial automation. This component is rated for 4W and operates within an ambient temperature range of -40°C to 150°C (TJ).
Additional Information
Series: LinkSwitch®-HFRoHS Status: RoHS CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SMD (7 Leads), Gull Wing |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Duty Cycle | 63% |
| Frequency - Switching | 200kHz |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 700V |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Supplier Device Package | SMD-8B |
| Fault Protection | Current Limiting, Open Loop, Over Temperature, Short Circuit |
| Control Features | - |
| Power (Watts) | 4 W |
