EM027BS013
GRAPHIC DISPLAY TFT BLACK 2.7Manufacturer: Pervasive Displays
Categories: LCD, OLED, Graphic
Quality Control: Learn More
Pervasive Displays EM027BS013 is a 2.7-inch (68.58mm) monochrome graphic TFT display module utilizing Electronic Paper Display (EPD) technology. This reflective display offers a 264 x 176 pixel resolution, rendering graphics in black on a white background without a backlight. The EM027BS013 features a compact viewing area of 57.29mm W x 38.19mm H and communicates via a serial peripheral interface (SPI). This component is well-suited for applications requiring low power consumption and excellent readability in various lighting conditions, commonly found in industrial automation, smart signage, and portable instrumentation.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Display Type | TFT - Electronic Paper Display (EPD) |
| Display Mode | Reflective |
| Backlight | Without Backlight |
| Interface | SPI |
| Viewing Area | 57.29mm W x 38.19mm H |
| Dot Pixels | 264 x 176 |
| Diagonal Screen Size | 2.7"" (68.58mm) |
| Background Color | White |
| Graphics Color | Black |
| Touchscreen | - |
