PJX8839_R1_00001
60V P-CHANNEL ENHANCEMENT MODE MManufacturer: Panjit International Inc.
Categories: FET, MOSFET Arrays
Quality Control: Learn More
Mosfet Array 60V 200mA (Ta) 300mW (Ta) Surface Mount SOT-563
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-563, SOT-666 |
| Mounting Type | Surface Mount |
| Configuration | 2 P-Channel (Dual) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 300mW (Ta) |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 200mA (Ta) |
| Input Capacitance (Ciss) (Max) @ Vds | 51pF @ 25V |
| Rds On (Max) @ Id, Vgs | 4Ohm @ 500mA, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 1.1nC @ 4.5V |
| FET Feature | - |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Supplier Device Package | SOT-563 |
Request a Quote
