P22-4F-C
CONN SPADE TERM 22-26AWG #4Manufacturer: Panduit Corp
Categories: Spade Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® P22-4F-C is a non-insulated, standard spade terminal designed for crimp termination. This component accommodates wire gauges from 22 to 26 AWG, with a stud size of #4. Constructed from copper with a tin contact finish, it features a brazed seam for enhanced durability. The terminal has an overall length of 0.490 inches (12.45mm) and a width of 0.190 inches (4.83mm). Its free hanging (in-line) mounting type makes it suitable for various electrical connection applications. This part is supplied in bulk packaging. It finds application in the telecommunications and industrial automation sectors.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Brazed Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | - |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 22-26 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Standard |
| Stud/Tab Size | 4 Stud |
| Length - Overall | 0.490"" (12.45mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.190"" (4.83mm) |
| Contact Material | Copper |
