EV18-8LFBK-Q
STRONGHOLD LOCKING FORK TERMINALManufacturer: Panduit Corp
Categories: Spade Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ EV18-8LFBK-Q is a blue, insulated, crimp-style spade terminal connector designed for 18-22 AWG wire. Featuring a tin-plated copper contact with a butted seam, this component is engineered for reliable electrical connections. The terminal type is spring, snap, with a free hanging (in-line) mounting configuration. It accommodates an 8 stud size and has an overall length of 0.830 inches (21.08mm) and an outer width of 0.280 inches (7.11mm). This Panduit Corp StrongHold™ terminal is suitable for applications in the industrial automation, automotive, and telecommunications sectors. Packaging is in bulk.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 18-22 AWG |
| Insulation | Insulated |
| Terminal Type | Spring, Snap |
| Stud/Tab Size | 8 Stud |
| Length - Overall | 0.830"" (21.08mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.280"" (7.11mm) |
| Contact Material | Copper |
