EV18-8FBK-L
STRONGHOLD FORK TERMINAL, VINYLManufacturer: Panduit Corp
Categories: Spade Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ EV18-8FBK-L is a red, insulated fork terminal designed for crimp termination of 18-22 AWG wire. This terminal features a vinyl insulation and a tin-plated copper contact for reliable electrical connection. The butted seam construction ensures a secure crimp, critical for high-vibration environments. With an 8 stud size and a terminal type of standard, it is suitable for inline, free-hanging applications. Its overall length is 0.830 inches (21.08mm) and the outer edges measure 0.280 inches (7.11mm). This component finds application in industries such as automotive, industrial automation, and telecommunications where robust and dependable electrical connections are paramount. The product is supplied in bulk packaging.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 18-22 AWG |
| Insulation | Insulated |
| Terminal Type | Standard |
| Stud/Tab Size | 8 Stud |
| Length - Overall | 0.830"" (21.08mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.280"" (7.11mm) |
| Contact Material | Copper |
