EV18-6LFBK-Q
STRONGHOLD LOCKING FORK TERMINALManufacturer: Panduit Corp
Categories: Spade Connectors
Quality Control: Learn More
The Panduit Corp StrongHold™ EV18-6LFBK-Q is a blue, insulated spade terminal connector designed for crimp termination of 18-22 AWG wire. Featuring a butted seam construction and a tin-plated copper contact for reliable conductivity, this component utilizes a spring, snap terminal type. With an overall length of 0.830 inches (21.08mm) and a 0.250 inch (6.35mm) outer width, it is suitable for free hanging (in-line) mounting applications. The terminal accommodates a 6 stud size. This component is commonly employed in industrial automation, telecommunications, and power distribution systems. It is supplied in bulk packaging.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 18-22 AWG |
| Insulation | Insulated |
| Terminal Type | Spring, Snap |
| Stud/Tab Size | 6 Stud |
| Length - Overall | 0.830"" (21.08mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.250"" (6.35mm) |
| Contact Material | Copper |
