EV18-10LFBK-L
STRONGHOLD LOCKING FORK TERMINALManufacturer: Panduit Corp
Categories: Spade Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ EV18-10LFBK-L is a blue, insulated spade terminal connector designed for crimp termination of 18-22 AWG wire. Featuring a butted seam construction and a tin-plated copper contact, this terminal utilizes a spring, snap terminal type for secure connection. The free-hanging mounting allows for in-line application. With a 10 stud size and an overall length of 0.830 inches (21.08mm), this component is suitable for applications in industrial automation, telecommunications, and automotive sectors. The product is supplied in bulk packaging.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 18-22 AWG |
| Insulation | Insulated |
| Terminal Type | Spring, Snap |
| Stud/Tab Size | 10 Stud |
| Length - Overall | 0.830"" (21.08mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.320"" (8.13mm) |
| Contact Material | Copper |
