EV18-10FBK-Q
STRONGHOLD FORK TERMINAL, VINYLManufacturer: Panduit Corp
Categories: Spade Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ Fork Terminal, EV18-10FBK-Q, offers a robust crimp termination for 18-22 AWG wire. This red vinyl-insulated terminal features a standard spade design with a 10 stud size and a free-hanging (in-line) mounting type. Constructed from copper with a tin contact finish, it utilizes a butted seam construction for enhanced durability. The overall length measures 0.830 inches (21.08mm) with an outer width of 0.370 inches (9.40mm). This component is suitable for applications within the industrial and electrical sectors. It is supplied in bulk packaging.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 18-22 AWG |
| Insulation | Insulated |
| Terminal Type | Standard |
| Stud/Tab Size | 10 Stud |
| Length - Overall | 0.830"" (21.08mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.370"" (9.40mm) |
| Contact Material | Copper |
