EV14-8LFBK-L
STRONGHOLD LOCKING FORK TERMINALManufacturer: Panduit Corp
Categories: Spade Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ EV14-8LFBK-L is a blue, insulated spade terminal connector designed for crimp termination of 14-16 AWG wire. This component features a butted seam construction for enhanced durability and a tin-plated copper contact material for reliable conductivity. Engineered with a spring terminal type for secure connections, it offers a free hanging (in-line) mounting configuration. The terminal is specified with an 8 stud size and measures 0.830" (21.08mm) in overall length and 0.280" (7.11mm) in outer width. Applications for this Panduit Corp StrongHold™ terminal span industrial automation, telecommunications, and automotive sectors where robust electrical connections are critical. It is supplied in bulk packaging.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 14-16 AWG |
| Insulation | Insulated |
| Terminal Type | Spring, Snap |
| Stud/Tab Size | 8 Stud |
| Length - Overall | 0.830"" (21.08mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.280"" (7.11mm) |
| Contact Material | Copper |
