EV14-6LFBK-Q
STRONGHOLD LOCKING FORK TERMINALManufacturer: Panduit Corp
Categories: Spade Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ EV14-6LFBK-Q is a blue, insulated locking fork terminal designed for 14-16 AWG wire. This component features a butted seam construction and is manufactured from tin-plated copper for reliable conductivity. The terminal offers a 6 stud size for secure mounting and a free-hanging (in-line) mounting type. With an overall length of 0.830 inches (21.08mm) and an outer width of 0.240 inches (6.10mm), it is suitable for crimp termination. Applications for this terminal include industrial automation, power distribution, and telecommunications infrastructure. Supplied in bulk packaging.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 14-16 AWG |
| Insulation | Insulated |
| Terminal Type | Spring, Snap |
| Stud/Tab Size | 6 Stud |
| Length - Overall | 0.830"" (21.08mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.240"" (6.10mm) |
| Contact Material | Copper |
