S8-56R-Q
CONN RING FLAT 8AWG #5/16 CRIMPManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® S8-56R-Q is a non-insulated ring terminal connector designed for 8 AWG wire. This component features a 5/16 stud size with a flat-sided terminal type for enhanced contact surface area. The crimp termination utilizes a funnel opening to facilitate wire insertion and ensure a reliable connection. Constructed from copper with a tin contact finish, it offers excellent conductivity and corrosion resistance. The overall length measures 1.300 inches (33.02mm) with a thickness of 0.050 inches (1.27mm) and an outer width of 0.600 inches (15.24mm). Mounting is of the free hanging, in-line type. This component is commonly employed in industrial power distribution and heavy equipment manufacturing. It is supplied in bulk packaging.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | - |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Thickness | 0.050"" (1.27mm) |
| Terminal Type | Flat Sided |
| Stud/Tab Size | 5/16 Stud |
| Length - Overall | 1.300"" (33.02mm) |
| Termination | Crimp, Funnel Opening |
| Width - Outer Edges | 0.600"" (15.24mm) |
| Contact Material | Copper |
