S4-10R-T
CONN RING FLAT 4AWG #10 CRIMPManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® S4-10R-T is a non-insulated ring terminal designed for robust electrical connections. This connector accommodates 4 AWG wire and features a #10 stud size with a flat sided terminal type. The overall length is 1.208 inches (30.68mm) with a thickness of 0.090 inches (2.29mm) and an outer width of 0.550 inches (13.97mm). Manufactured from copper with a tin contact finish, it utilizes a crimp termination method with a funnel opening for reliable wire insertion. The mounting type is free hanging (in-line). This component is commonly utilized in industrial automation, power distribution, and automotive applications where secure and durable wire terminations are critical. It is supplied in bulk packaging.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | - |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 4 AWG |
| Insulation | Non-Insulated |
| Thickness | 0.090"" (2.29mm) |
| Terminal Type | Flat Sided |
| Stud/Tab Size | 10 Stud |
| Length - Overall | 1.208"" (30.68mm) |
| Termination | Crimp, Funnel Opening |
| Width - Outer Edges | 0.550"" (13.97mm) |
| Contact Material | Copper |
