PV6-12R-T
CONN RING FLAT 6AWG #1/2 CRIMPManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® PV6-12R-T is a blue, insulated ring terminal designed for reliable wire termination. This component utilizes a crimp termination method and is suitable for 6 AWG wire. The terminal features a 1/2" stud size and a flat-sided terminal type for enhanced conductivity. Constructed from copper with a tin contact finish, it incorporates a brazed seam for increased durability. The overall length is 1.840" (46.74mm) with a thickness of 0.045" (1.14mm) and an outer width of 0.820" (20.83mm). This component is offered in bulk packaging and is suitable for free-hanging (in-line) mounting. Applications include industrial automation, power distribution, and telecommunications infrastructure.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Brazed Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 6 AWG |
| Insulation | Insulated |
| Thickness | 0.045"" (1.14mm) |
| Terminal Type | Flat Sided |
| Stud/Tab Size | 1/2 Stud |
| Length - Overall | 1.840"" (46.74mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.820"" (20.83mm) |
| Contact Material | Copper |
