PV2-12R-XY
CONN RING D-SHAPE 2AWG #1/2Manufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® PV2-12R-XY is an insulated, D-shaped ring terminal connector designed for reliable crimp termination. This component accommodates 2 AWG wire and features a 1/2" stud size with a tin contact finish for optimal conductivity. Constructed from copper with a brazed seam for enhanced durability, the PV2-12R-XY offers a robust solution for electrical connections. Its overall length is 2.050" (52.07mm) with an outer width of 0.860" (21.84mm) and a thickness of 0.060" (1.52mm). The red insulation provides clear visual identification. This terminal is suitable for free hanging (in-line) mounting applications and is commonly utilized in power distribution, industrial automation, and heavy equipment sectors. Supplied in bulk packaging.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Brazed Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 2 AWG |
| Insulation | Insulated |
| Thickness | 0.060"" (1.52mm) |
| Terminal Type | D-Shaped |
| Stud/Tab Size | 1/2 Stud |
| Length - Overall | 2.050"" (52.07mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.860"" (21.84mm) |
| Contact Material | Copper |
