PV18-6R-E
CONN RING CIRC 18-22AWG #6 CRIMPManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
The Panduit Corp Pan-Term® PV18-6R-E is a red, insulated ring terminal connector designed for 18-22 AWG wire. This circular terminal features a tin-plated copper contact with a brazed seam and serrated termination for robust electrical connections. The PV18-6R-E has a stud size of #6 and a crimp termination type. Its in-line mounting allows for free-hanging applications. The overall length is 0.860 inches (21.84mm) with a thickness of 0.032 inches (0.81mm) and an outer width of 0.250 inches (6.35mm). This component is typically utilized in industrial automation and electrical infrastructure applications. It is supplied in bulk packaging.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Brazed Seam, Serrated Termination |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 18-22 AWG |
| Insulation | Insulated |
| Thickness | 0.032"" (0.81mm) |
| Terminal Type | Circular |
| Stud/Tab Size | 6 Stud |
| Length - Overall | 0.860"" (21.84mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.250"" (6.35mm) |
| Contact Material | Copper |
Request a Quote
