PK2-10R-T
CONN RING CIRC 2AWG #10 CRIMPManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® PK2-10R-T is an insulated circular ring terminal connector designed for #10 stud sizes. This component utilizes a 2 AWG wire gauge and is constructed from copper with a tin contact finish. Key features include a brazed seam for enhanced durability and serrated termination to ensure superior electrical contact. The overall length measures 1.950 inches (49.53mm) with a thickness of 0.060 inches (1.52mm) and an outer width of 0.680 inches (17.27mm). The free-hanging (in-line) mounting type is suitable for various applications. This connector is typically employed in industrial, automotive, and telecommunications sectors where robust and reliable electrical connections are critical. The natural color with a red stripe aids in identification. Packaged in bulk.
Additional Information
Series: Pan-Term®RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Brazed Seam, Serrated Termination |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Natural, Red Stripe |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 2 AWG |
| Insulation | Insulated |
| Thickness | 0.060"" (1.52mm) |
| Terminal Type | Circular |
| Stud/Tab Size | 10 Stud |
| Length - Overall | 1.950"" (49.53mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.680"" (17.27mm) |
| Contact Material | Copper |
