P8-8RHT6-Q
CONN RING D-SHAPE 8AWG #8 CRIMPManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® P8-8RHT6-Q is a non-insulated, D-shaped ring terminal designed for crimp termination of 8 AWG wire. This connector features a copper contact material with a nickel finish and a brazed seam for enhanced durability. The overall length is 1.120 inches (28.45mm), with an outer width of 0.420 inches (10.67mm) and a thickness of 0.040 inches (1.02mm). It is engineered to accept an 8 stud size and is suitable for free-hanging (in-line) mounting. This component is commonly utilized in industrial and electrical equipment manufacturing. Packaging is provided in bulk.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Brazed Seam |
| Packaging | Bulk |
| Contact Finish | Nickel |
| Color | - |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Thickness | 0.040"" (1.02mm) |
| Terminal Type | D-Shaped |
| Stud/Tab Size | 8 Stud |
| Length - Overall | 1.120"" (28.45mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.420"" (10.67mm) |
| Contact Material | Copper |
