EV18-14RBK-L
STRONGHOLD RING TERMINAL, VINYLManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ EV18-14RBK-L is a red, insulated ring terminal designed for 18-22 AWG wire. This circular terminal features a 1/4 Stud size and is constructed with a copper contact material and tin contact finish. The terminal utilizes a butted seam construction and a vinyl insulation for robust performance. With an overall length of 1.060 inches (26.92mm), a thickness of 0.030 inches (0.76mm), and an outer width of 0.460 inches (11.68mm), it offers a free-hanging (in-line) mounting type. This component is suitable for crimp termination and is supplied in bulk packaging. It finds application in industries such as automotive, industrial automation, and telecommunications for secure wire connections.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 18-22 AWG |
| Insulation | Insulated |
| Thickness | 0.030"" (0.76mm) |
| Terminal Type | Circular |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | 1.060"" (26.92mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.460"" (11.68mm) |
| Contact Material | Copper |
Request a Quote
