EV14-8RBK-L
STRONGHOLD RING TERMINAL, VINYLManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ Ring Terminal, VINYL, EV14-8RBK-L. This insulated circular ring terminal is designed for 14-16 AWG wire, accommodating an 8 stud size. Featuring a tin-plated copper contact material and a butted seam construction, it ensures reliable termination. The vinyl insulation provides robust protection. This component is suitable for applications in the industrial automation and telecommunications sectors, offering a free-hanging, in-line mounting type. The overall length is 0.860 inches with a thickness of 0.032 inches and a width of 0.330 inches. Packaged in bulk.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 14-16 AWG |
| Insulation | Insulated |
| Thickness | 0.032"" (0.81mm) |
| Terminal Type | Circular |
| Stud/Tab Size | 8 Stud |
| Length - Overall | 0.860"" (21.84mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.330"" (8.38mm) |
| Contact Material | Copper |
