EV14-6RBK-L
STRONGHOLD RING TERMINAL, VINYLManufacturer: Panduit Corp
Categories: Ring Connectors
Quality Control: Learn More
Panduit Corp StrongHold™ EV14-6RBK-L is a blue, insulated ring terminal designed for 14-16 AWG wire. This circular terminal features a tin-plated copper contact for excellent conductivity and a butted seam construction for reliable crimp termination. The overall length is 0.860 inches (21.84mm) with a stud size of #6. The terminal has a thickness of 0.032 inches (0.81mm) and an outer width of 0.330 inches (8.38mm). Manufactured with a vinyl insulation, it offers a free-hanging (in-line) mounting type. This component is suitable for applications in industrial, automotive, and electrical infrastructure where secure and durable wire connections are critical. The EV14-6RBK-L is supplied in bulk packaging.
Additional Information
Series: StrongHold™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Bulk |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 14-16 AWG |
| Insulation | Insulated |
| Thickness | 0.032"" (0.81mm) |
| Terminal Type | Circular |
| Stud/Tab Size | 6 Stud |
| Length - Overall | 0.860"" (21.84mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.330"" (8.38mm) |
| Contact Material | Copper |
