DV18-250MB-3K
CONN QC TAB 18-22AWG 0.250 CRIMPManufacturer: Panduit Corp
Categories: Quick Connects, Quick Disconnect Connectors
Quality Control: Learn More
Panduit Corp Disco™ series male quick connect, part number DV18-250MB-3K. This 0.250" (6.35mm) wide tab connector features a 0.032" (0.81mm) thickness and is designed for 18-22 AWG wire with a crimp termination. The unit is supplied on tape and reel for high-volume applications. Its non-mating end is insulated, and it utilizes a butted seam construction for enhanced durability. This connector is suitable for in-line, free-hanging applications and is commonly found in industrial automation, automotive, and appliance manufacturing sectors.
Additional Information
Series: Disco™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Butted Seam |
| Packaging | Tape & Reel (TR) |
| Gender | Male |
| Contact Finish | - |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 18-22 AWG |
| Insulation | Non-Mating End Insulated |
| Terminal Type | Standard |
| Length - Overall | 0.900"" (22.86mm) |
| Termination | Crimp |
| Tab Thickness | 0.032"" (0.81mm) |
| Tab Width | 0.250"" (6.35mm) |
| Tab Length | - |
| Contact Material | - |
