DV14-250P-EYY
CONN QC RCPT/TAB 14-16AWG 0.250Manufacturer: Panduit Corp
Categories: Quick Connects, Quick Disconnect Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® DV14-250P-EYY is a blue, crimp-style quick connect receptacle and tab set designed for 14-16 AWG wire. Featuring a 0.250" (6.35mm) tab width and 0.032" (0.81mm) tab thickness, this connector set offers brass contacts with a tin finish for reliable conductivity. The non-mating end is insulated for enhanced safety and performance. With a free-hanging (in-line) mounting type and an overall length of 0.880" (22.35mm), this component is suitable for various industrial applications including automotive, telecommunications, and general electrical equipment where secure and efficient wire termination is required. The terminal type is stacked.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Gender | Female and Male |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 14-16 AWG |
| Insulation | Non-Mating End Insulated |
| Terminal Type | Stacked |
| Length - Overall | 0.880"" (22.35mm) |
| Termination | Crimp |
| Tab Thickness | 0.032"" (0.81mm) |
| Tab Width | 0.250"" (6.35mm) |
| Tab Length | - |
| Contact Material | Brass |
