DNH14-250FIM-Q
CONN QC TAB 14-16AWG 0.250 CRIMPManufacturer: Panduit Corp
Categories: Quick Connects, Quick Disconnect Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® DNH14-250FIM-Q is a male, fully insulated heat shrink quick connect terminal designed for 14-16 AWG wire gauges. It features a 0.250" (6.35mm) tab width and 0.032" (0.81mm) tab thickness with a tin contact finish on brass material. This free-hanging (in-line) mount component offers a crimp termination method and is supplied in bulk packaging. The blue, fully insulated heat shrink insulation provides robust protection in demanding applications. This terminal is commonly employed in industrial automation, automotive, and telecommunications sectors where reliable and secure electrical connections are critical.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Gender | Male |
| Contact Finish | Tin |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 14-16 AWG |
| Insulation | Fully Insulated Heat Shrink |
| Terminal Type | Standard |
| Length - Overall | 1.500"" (38.10mm) |
| Termination | Crimp |
| Tab Thickness | 0.032"" (0.81mm) |
| Tab Width | 0.250"" (6.35mm) |
| Tab Length | - |
| Contact Material | Brass |
