DNH10-250FI-E
CONN QC RCPT 10-12AWG 0.250Manufacturer: Panduit Corp
Categories: Quick Connects, Quick Disconnect Connectors
Quality Control: Learn More
Panduit Corp Pan-Term® DNH10-250FI-E is a female, fully insulated heat shrink quick connect receptacle designed for 10-12 AWG wire. This component features a 0.250" (6.35mm) tab width and 0.032" (0.81mm) tab thickness with a tin contact finish on brass material. The free hanging (in-line) mounting type and crimp termination ensure reliable connections. Its overall length is 1.440" (36.58mm). This connector is utilized in industrial automation, power distribution, and electrical equipment manufacturing. Offered in bulk packaging.
Additional Information
Series: Pan-Term®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Gender | Female |
| Contact Finish | Tin |
| Color | Yellow |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 10-12 AWG |
| Insulation | Fully Insulated Heat Shrink |
| Terminal Type | Standard |
| Length - Overall | 1.440"" (36.58mm) |
| Termination | Crimp |
| Tab Thickness | 0.032"" (0.81mm) |
| Tab Width | 0.250"" (6.35mm) |
| Tab Length | - |
| Contact Material | Brass |
