LCDX4-14D-L
CONN TERM RECT TONG 4 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
The Panduit Corp Pan-Lug™ LCDX4-14D-L is a non-insulated rectangular tongue terminal designed for 4 AWG wire. This component features a crimp barrel termination and is manufactured with a 1/4 stud size. The overall length is 2.350 inches (59.69mm) with an outer width of 0.550 inches (13.97mm) and a tab thickness of 0.090 inches (2.29mm). It offers a free hanging (in-line) mounting type and a terminal style with two stud holes, facilitating secure connections. This component is commonly utilized in industrial electrical systems and power distribution applications. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Gray |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 4 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | 2.350"" (59.69mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.550"" (13.97mm) |
| Tab Thickness | 0.090"" (2.29mm) |
| Terminal Style | Two Stud Holes |
