LCD8-14BH-L
CONN TERM RECT TONG 8 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD8-14BH-L is a non-insulated, rectangular tongue terminal connector designed for robust electrical connections. This component is engineered for 8 AWG wire gauge and features a 1/4 inch stud/tab size with a tab thickness of 0.070 inches. The terminal style includes two stud holes, facilitating secure mounting. Its termination method is crimp, utilizing a barrel design for reliable wire engagement. The overall width of the outer edges measures 0.480 inches. Commonly utilized in power distribution, industrial automation, and heavy equipment sectors, this component is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.480"" (12.19mm) |
| Tab Thickness | 0.070"" (1.78mm) |
| Terminal Style | Two Stud Holes |
